NOTES :
All dimensions are in mm unless otherwise specified.
Views and dimensions are typical. They may change in specific cases.
l
l
AUTOAIRRELEASEVALVE: NS
NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
PARTNAME
MATERIAL
VALVEBODY
COVER
FLOAT
LEVERS& LINKS
PIVOTBRACKET
SETPIN
SEALINGMEMBER
NOZZLE
FIXINGSCREW
HEX. HEADSCREW
GASKET
(CLEAN/DRAIN) PORTPLUG.
C.I. IS210Gr. FG260
C.I. IS210Gr. FG260
ST. ST. AISI 410
ST. ST. AISI 410
MILDSTEEL
ST. ST. AISI 410
S.S. +NITRILERUBBER
BR. IS318Gr. LTB2
S.S. AISI 304
C.S. Is1367Cl. 4.6/4
NITRILERUBBER
ST. ST. AISI 410
DN (Size)
½ ”
3/4”
1"
A
160
170
185
ØB
132
140
150
*ØC
1.3
2.0
3.0
*NOTE :-OPTIONALPORTSIZESPOSSIBLE.
l
Maximized flow area.
l
Combination of Air-Vacuum & Air Release Valves.
l
Guided floats of Stainless Steel material.
l
Sturdy and Robust construction.
l
Strong floats which preclude the possibility of necking / deformation due to pressure.
l
Choice of MOC including CI / SGI / CS / SS / D2 to suit applications.
l
PN 10 / 16 / 25 Pressure Ratings. (Enquire for Others.)
l
Complies with the requirements of IS 14845 & AWWA - C512.
SALIENT FEATURES :
l
Efficient Aero-dynamic flow passages.
l
One Piece Tamper-proof Cover.
l
Straight through Air release opening of large size.
l
Guaranteed long life resilient seats.
l
Floats of optimum specific gravity ensuring quick response to level changes.
l
Aerodynamic performance tested & proven at FCRI.
l
Many, many successful, prestigious installations.
SPECIALFEATURES :
