SINGLECHAMBERCOMBINATION
TYPE TAMPER-PROOF AIR VALVE
COMBINATIONTYPE
TAMPER - PROOF AIRVALVE
NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
PARTNAME
MATERIAL
VALVEBODY
FLOAT
NOZZLE
GASKET
COVER
STUDS&NUTS
AUTOVALVEBODY
AUTOVALVE FLOAT
BOLTS&NUTS
AUTOVALVENOZZLE
AUTOVALVECOVER
AUTOVALVEGASKET
C.I. IS210Gr. FG 260
ST. STEELAISI 304
BRONZE IS 318 LTB2+NITRILERUBBER
NITRILERUBBER
C.I. IS 210Gr. FG 260
CARBONSTEEL
C.I. IS 210Gr. FG 260
ST. STEELAISI 304
CARBONSTEEL
BRONZE IS 318 LTB2+NITRILERUBBER
C.I. IS 210Gr. FG260
NITRILERUBBER
AIRRELEASEVALVE: NS
NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
PARTNAME
MATERIAL
VALVEBODY
COVER
FLOATWITHGUIDE-BAR
BEARINGBUSH
CUSHIONBUSH
SEALRING
CLAMPINGRING
GASKET
HEX. HEADSCREW
DRAIN&CLEANINGPLUG
C.I. IS 210Gr. FG 260
ST. ST. AISI 304
BR. IS 318Gr. LTB2
NITRILERUBBER
NITRILERUBBER
ST. ST. AISI 410
NITRILERUBBER
C.S. IS1367Cl.4.6/4
CARBONSTEELGALVANIZED.
C.I. IS 210Gr. FG 260
*DN (Size)
A ØB ØD T
100mm
150mm
200mm
390
490
545
250
325
418
220
285
340
22
23
24.5
* : LARGERSIZESONREQUEST.
DN (Size) A ØB ØD T
50mm
80mm
100mm
150mm
200mm
335
365
390
500
550
190
210
230
305
390
165
200
220
285
340
16
21
22
23
24.5
